G TECH 25.6V 200Ah LiFePO4 Battery with 6000 Cycle Life for Solar Energy Storage
Productdetails
| Materiaal | LiFePO4 | ||
|---|---|---|---|
| Markeren | 25.6V 200Ah LiFePO4 solar battery,LiFePO4 battery pack with 6000 cycles,solar energy storage LiFePO4 battery |
||
Productomschrijving
Product Advantages
- Totally new A Grade EVE , BYD, CALB CETC Cells
- 6000 life cycle
- Bluetooth function optional
For solar energy storage
| 序号 NO. |
项目 Item |
常用参数 General Parameter |
备注 Remark |
||||
|---|---|---|---|---|---|---|---|
| 1 | 型号(Model) | LK25.6-200 | |||||
| 2 | 典型容量(0.2C5A) Standard capacity(0.2C5A) |
200Ah | |||||
| 3 | 最小容量(0.2C5A) Minimum Capacity(0.2C5A) |
198Ah | |||||
| 4 | 额定电压 Rated voltage | 25.6V | |||||
| 5 | 最大充电电压 Max Charge voltage | 29.2V | |||||
| 6 | 放电截至电压 Cut-off voltage | 20V | |||||
| 7 | 标准充放电 Standard charge and discharge current |
40A | |||||
| 最大充电电流 Maximum Continuous Charge Current |
200A | 见充电策略表 | |||||
| 8 | 最大持续放电电流 Max Continuous discharge current |
200A | 见放电策略表 | ||||
| 9 | 电池重量(Approx.) Weight(Approx including case) |
≈ 40.8 Kg | |||||
| 10 | 内阻(Max, at 1000Hz.) Impedance(Max, at 1000Hz.) |
≤8mΩ | 包括测试夹具内阻 Includes test fixture internal resistance |
||||
| 11 | 出货 SOC Battery Shipping SOC | 30%±5% SOC | 空运 Air freight | ||||
| 65%±5% SOC | 海运 Sea transport | ||||||
